Huawei Mate 70 Pro+ - Specifications
Brand and model
Information about the brand, model and model alias (if any) of a specific device.
Brand Brand name of the company that manufactures the device. | Huawei |
Model Model name of the device. | Mate 70 Pro+ |
Model alias Аlternative names, under which the model is known. | Mate 70 Pro Plus PLA-AL10 |
Design
Information about the dimensions and weight of the device, shown in different measurement units. Body materials, available colors, certifications.
Width Information about the width, i.e. the horizontal side of the device when it is used in its standard orientation. | 79.5 mm (millimeters) 7.95 cm (centimeters) 0.261 ft (feet) 3.13 in (inches) |
Height Information about the height, i.e. the vertical side of the device when it is used in its standard orientation. | 164.6 mm (millimeters) 16.46 cm (centimeters) 0.54 ft (feet) 6.48 in (inches) |
Thickness Information about the thickness/depth of the device in different measurement units. | 8.25 mm (millimeters) 0.825 cm (centimeters) 0.027 ft (feet) 0.325 in (inches) |
Weight Information about the weight of the device in different measurement units. | 226 g (grams) 0.5 lbs (pounds) 7.97 oz (ounces) |
Volume Estimated volume of the device, calculated from the dimensions provided by the manufacturer. Applies for devices in the form of a rectangular parallelepiped. | 107.96 cm³ (cubic centimeters) 6.56 in³ (cubic inches) |
Colors Information about the colors, in which the device is available in the market. | Gold and Silver Brocade Flying Sky Blue Feather White Ink Rhyme Black |
Body materials Materials used in the fabrication of the device's body. | Glass Titanium |
Certification Information about the standards, in which the device is certified. | IP68 IP69 |
SIM card
The Subscriber Identity Module (SIM) is used in mobile devices for storing data authenticating the subscribers of mobile services.
SIM card type Information about the type and size (form factor) of the SIM card used in the device. | Nano-SIM (4FF - fourth form factor, since 2012, 12.30 x 8.80 x 0.67 mm) |
Number of SIM cards Information about the number of SIM cards, supported by the device. | 2 |
Networks
A mobile (cellular) network is a radio system, which allows a large number of mobile devices to communicate with each other.
GSM GSM (Global System for Mobile Communications) was developed to replace the analog cellular network (1G), therefore it is referred to as a 2G mobile network. It has been improved with the addition of General Packet Radio Services (GPRS) and later via the Enhanced Data rates for GSM Evolution (EDGE) technology. | GSM 850 MHz (B5) GSM 900 MHz (B8) GSM 1800 MHz (B3) GSM 1900 MHz (B2) |
W-CDMA W-CDMA (Wideband Code Division Multiple Access) is an air interface used by 3G mobile networks. It is one of the three different UMTS interfaces together with the TD-SCDMA and the TD-CDMA. The standard provides faster data transfer speeds and allows more users to connect to the network simultaneously. | W-CDMA 850 MHz (B5) W-CDMA 850 MHz (B6) W-CDMA 900 MHz (B8) W-CDMA 900 MHz (B19) W-CDMA 1700 MHz (B4) W-CDMA 1800 MHz (B3) W-CDMA 1900 MHz (B2) W-CDMA 2100 MHz (B1) |
LTE LTE is deemed to be the fourth generation (4G) of mobile communications technology. It has been developed by the 3GPP based on the GSM/EDGE and UMTS/HSPA technologies in order to increase the speed and capacity of wireless data networks. A further development of the technology is called LTE Advanced. | LTE-FDD 700 MHz (B12) LTE-FDD 700 MHz (B17) LTE-FDD 700 MHz (B28) LTE-FDD 800 MHz (B20) LTE-FDD 850 MHz (B5) LTE-FDD 850 MHz (B18) LTE-FDD 850 MHz (B19) LTE-FDD 850 MHz (B26) LTE-FDD 900 MHz (B8) LTE-FDD 1500 MHz (B32) LTE-FDD 1700 MHz (B4) LTE-FDD 1800 MHz (B3) LTE-FDD 1900 MHz (B2) LTE-FDD 2100 MHz (B1) LTE-FDD 2600 MHz (B7) LTE-TDD 1900 MHz (B39) LTE-TDD 2000 MHz (B34) LTE-TDD 2300 MHz (B40) LTE-TDD 2500 MHz (B41) LTE-TDD 2600 MHz (B38) |
5G NR The 5G (fifth generation) mobile networks use the new radio access technology (RAT) developed by 3GPP, dubbed 5G NR and deemed as the global standard for the air interface of 5G networks. 5G NR operates in two frequency ranges - FR1 (sub-6 GHz) and FR2 (above 24 GHz). In the FR1 frequency range, the 5G mobile networks use a number of bands, some of which are traditionally used by previous standards. The FR2 provides shorter range but higher available bandwidth than bands in the FR1. | 5G-FDD 700 MHz (n28) 5G-FDD 800 MHz (n20) 5G-FDD 850 MHz (n5) 5G-FDD 900 MHz (n8) 5G-FDD 1800 MHz (n3) 5G-FDD 2100 MHz (n1) 5G-TDD 2300 MHz (n40) 5G-TDD 2500 MHz (n41) 5G-TDD 3500 MHz (n78) 5G-TDD 3700 MHz (n77) |
Mobile network technologies and bandwidth
Communication between devices within mobile networks is realized via various generations of network technologies, which provide different bandwidth.
Mobile network technologies There are several network technologies that enhance the performance of mobile networks mainly by increased data bandwidth. Information about the communication technologies supported by the device and their respective uplink and downlink bandwidth. | UMTS (384 kbit/s ) EDGE GPRS HSPA+ LTE EV-DO Rev. A (1.8 Mbit/s , 3.1 Mbit/s ) TD-SCDMA TD-HSDPA 5G SA 5G NSA |
Operating system
Operating system is the system software, which manages and controls the functioning of the hardware components of the device.
Operating system (OS) Information about the operating system used by the device as well as its version. | HarmonyOS 4.3 HarmonyOS Next 5.0 |
System on Chip (SoC)
A system on a chip (SoC) includes into a single chip some of the main hardware components of the mobile device.
SoC The SoC integrates different hardware components such as the CPU, GPU, memory, peripherals, interfaces, etc., as well as software for their functioning. | Huawei HiSilicon KIRIN 9020 |
Process technology Information about the process technology used in manufacturing the chip. The value in nanometers represents half the distance between elements that make up the CPU. | 7 nm (nanometers) |
CPU CPU is the Central Processing Unit or the processor of a mobile device. Its main function is to interpret and execute instructions contained in software applications. | 2 x 2.5 GHz Taishan V121, 6 x 2.151 GHz Taishan V121, 4 x 1.6 GHz ARM Cortex-A510 |
CPU bits The CPU bits are determined by the bit-size of the processor registers, address buses and data buses. 64-bit CPUs provide better performance than 32-bit ones, which on their part perform better than 16-bit processors. | 64 bit |
Instruction set The instruction set architecture (ISA) is a set of commands used by the software to manage the CPU's work. Information about the set of instructions the processor can execute. | ARMv9-A |
CPU cores A CPU core is the processor unit, which executes software instructions. Presently, besides single-core processors, there are dual-core, quad-core, hexa-core and so on multi-core processors. They increase the performance of the device allowing the execution of multiple instructions in parallel. | 8 |
CPU frequency The frequency of the processor describes its clock rate in cycles per second. It is measured in Megahertz (MHz) or Gigahertz (GHz). | 2500 MHz (megahertz) |
GPU GPU is a graphical processing unit, which handles computation for 2D/3D graphics applications. In mobile devices GPU is usually utilized by games, UI, video playback, etc. GPU can also perform computation in applications traditionally handled by the CPU. | Maleoon 920 |
GPU cores Similar to the CPU, the GPU consists of processing units called cores. They handle the computation of graphics in various applications. | 4 |
GPU frequency The frequency is the clock rate of the graphic processor (GPU), which is measured in Megahertz (MHz) or Gigahertz (GHz). | 840 MHz (megahertz) |
RAM capacity RAM (Random-Access Memory) is used by the operating system and all installed applications. Data in the RAM is lost after the device is turned off or restarted. | 16 GB (gigabytes) |
RAM type Information about the type of RAM used by the device. | LPDDR5 |
RAM channels Information about the number of RAM channels integrated in the SoC. More channels mean higher data transfer rates. | Quad channel |
RAM frequency RAM frequency relates directly to the rate of reading/writing from/in the RAM memory. | 3200 MHz (megahertz) |
Ark Engine 6870 mm² VC liquid cooling system |
Storage
Every mobile device has a built-in storage (internal memory) with a fixed capacity.
Storage Information about the capacity of the built-in storage of the device. Sometimes one and the same model may is offered in variants with different internal storage capacity. | 512 GB (gigabytes) 1024 GB (gigabytes) |
Display
The display of a mobile device is characterized by its technology, resolution, pixel density, diagonal length, color depth, etc.
Type/technology One of the main characteristics of the display is its type/technology, on which depends its performance. | OLED |
Diagonal size In mobile devices display size is represented by the length of its diagonal measured in inches. | 6.9 in (inches) 175.26 mm (millimeters) 17.53 cm (centimeters) |
Width Approximate width of the display | 2.91 in (inches) 73.86 mm (millimeters) 7.39 cm (centimeters) |
Height Approximate height of the display | 6.26 in (inches) 158.94 mm (millimeters) 15.89 cm (centimeters) |
Aspect ratio The ratio between the long and the short side of the display | 2.152:1 |
Resolution The display resolution shows the number of pixels on the horizontal and vertical side of the screen. The higher the resolution is, the greater the detail of the displayed content. | 1316 x 2832 pixels |
Pixel density Information about the number of pixels per centimeter (ppcm) or per inch (ppi) of the display. The higher the pixel density, the more detailed and clearer is the information displayed on the screen. | 453 ppi (pixels per inch) 178 ppcm (pixels per centimeter) |
Color depth The color depth of the display is also known as bit depth. It shows the number of bits used for the color components of one pixel. Information about the maximum number of colors the screen can display. | 30 bit 1073741824 colors |
Display area The estimated percentage of the screen area from the device's front area. | 90 % (percent) |
Other features Information about other functions and features of the display. | Capacitive Multi-touch Scratch resistant |
3D curved glass screen Kunlun Glass 2 LTPO 1-120 Hz refresh rate 300 Hz touch sampling rate 1440 Hz PWM 2500 cd/m² local peak brightness 100% DCI-P3 |
Sensors
Different sensors measure different physical quantities and convert them into signals recognizable by the mobile device.
Sensors Sensors vary in type and purpose. They increase the overall functionality of the device, in which they are integrated. | Proximity Light Accelerometer Compass Gyroscope Barometer Fingerprint Hall Gravity |
In-display fingerprint sensor Color temperature sensor Laser sensor X-axis linear motor |
Rear camera
The primary camera of the mobile device is usually placed on its back and can be combined with one or more additional cameras.
Sensor type Information about the sensor type of the camera. Some of the most widely used types of image sensors on mobile devices are CMOS, BSI, ISOCELL, etc. | CMOS BSI (backside illumination) |
Sensor format The optical format of an image sensor is an indication of its shape and size. It is usually expressed in inches. | 1/1.28" |
Aperture The aperture (f-stop number) indicates the size of the lens diaphragm opening, which controls the amount of light reaching the image sensor. The lower the f-stop number, the larger the diaphragm opening is, hence, the more light reaches the sensor. Usually, the f-stop number specified is the one that corresponds to the maximum possible diaphragm opening. | f/1.4 - 4 |
Focal length and 35 mm equivalent Focal length is the distance in millimeters from the focal point of the image sensor to the optical center of the lens. The 35 mm equivalent indicates the focal length at which a full-frame camera will achieve an angle of view that's the same as the one of the camera of the mobile device. It is measured by multiplying the native focal length of the camera by the crop factor of the sensor. The crop factor itself can be determined as the ratio between the diagonal distances of the image sensor in the 35 mm camera and a given sensor. | 24 mm (millimeters) *(35 mm / full frame) |
Flash type The rear cameras of mobile devices use mainly a LED flash. It may arrive in a single, dual- or multi-light setup and in different arrangements. | Dual LED |
Image resolution One of the main characteristics of the cameras is their image resolution. It states the number of pixels on the horizontal and vertical dimensions of the image, which can also be shown in megapixels that indicate the approximate number of pixels in millions. | 8192 x 6144 pixels 50.33 MP (megapixels) |
Video resolution Information about the maximum resolution at which the rear camera can shoot videos. | 3840 x 2160 pixels 8.29 MP (megapixels) |
Video FPS Information about the maximum number of frames per second (fps) supported by the rear camera while recording video at the maximum resolution. Some of the main standard frame rates for recording and playing video are 24 fps, 25 fps, 30 fps, 60 fps. | 60 fps (frames per second) |
Features Information about additional software and hardware features of the rear camera which improve its overall performance. | Autofocus Continuous shooting Digital zoom Optical zoom Digital image stabilization Optical image stabilization Geotagging Panorama HDR Touch focus Face detection White balance settings ISO settings Exposure compensation Self-timer Scene mode Macro mode Phase detection autofocus (PDAF) Contrast detection autofocus (CDAF) Laser autofocus (LAF) XMAGE technology |
Secondary rear camera - 40 MP (ultra-wide angle) Aperture size - f/2.2 (#2) Focal length (35 mm equivalent) - 13 mm (#2) Third rear camera - 48 MP (telephoto and macro) Aperture size - f/2.1 (#3) 4x optical zoom (#3) 100x digital zoom (#3) Focal length (35 mm equivalent) - 92.5 mm (#3) OIS (#3) Fourth rear camera - 1.5MP multi-spectral sensor |
Front camera
Modern smartphones have one or more front cameras and their positioning has led to various design concepts – pop-up camera, rotating camera, notch, punch hole, under-display camera, etc.
Sensor type Information about the sensor type of the camera. Some of the most widely used types of image sensors on mobile devices are CMOS, BSI, ISOCELL, etc. | CMOS BSI (backside illumination) |
Aperture The aperture (f-stop number) indicates the size of the lens diaphragm opening, which controls the amount of light reaching the image sensor. The lower the f-stop number, the larger the diaphragm opening is, hence, the more light reaches the sensor. Usually, the f-stop number specified is the one that corresponds to the maximum possible diaphragm opening. | f/2.4 |
Image resolution Information about the number of pixels on the horizontal and vertical dimensions of the photos taken by the front camera, indicated in megapixels as well. | 4160 x 3120 pixels 12.98 MP (megapixels) |
Video resolution Information about the maximum resolution of the videos shot by the front camera. | 3840 x 2160 pixels 8.29 MP (megapixels) |
Video FPS Digital cameras are able to shoot videos at different frames per second (fps). Some of the main standard frame rates for recording and playing video are 24 fps, 25 fps, 30 fps, 60 fps. Information about the maximum possible fps for shooting videos at the maximum possible resolution. | 30 fps (frames per second) |
Features Information about additional software and hardware features of the front camera which improve its overall performance. | Face unlock HDR |
Secondary front camera - 3D depth sensor |
Audio
Information about the type of speakers and the audio technologies supported by the device.
Speaker The loudspeaker is a device, which reproduces various sounds such as ring tones, alarms, music, voice calls, etc. Information about the type of speakers the device uses. | Loudspeaker Earpiece Stereo speakers |
Huawei Histen |
Radio
The radio in a mobile device is a built-in FM radio receiver.
Radio Information whether the device has an FM radio receiver or not. | No |
Tracking/Positioning
Information about the positioning and navigation technologies supported by the device.
Tracking/Positioning The tracking/positioning service is provided by various satellite navigation systems, which track the autonomous geo-spatial positioning of the device that supports them. The most common satellite navigation systems are the GPS and the GLONASS. There are also non-satellite technologies for locating mobile devices such as the Enhanced Observed Time Difference, Enhanced 911, GSM Cell ID. | GPS A-GPS NavIC GLONASS (L1+L5) Galileo (E1+E5a) BeiDou (B1I+B1C+B2a) QZSS (L1 + L5) |
Wi-Fi
Wi-Fi is a technology that provides wireless data connections between various devices within a short range.
Wi-Fi Wi-Fi communication between devices is realized via the IEEE 802.11 standards. Some devices have the possibility to serve as Wi-Fi Hotspots by providing internet access for other nearby devices. Wi-Fi Direct (Wi-Fi P2P) is another useful standard that allows devices to communicate with each other without the need for wireless access point (WAP). | 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz 802.11ac (IEEE 802.11ac) Wi-Fi 6 (IEEE 802.11ax) Dual band Wi-Fi Hotspot Wi-Fi Direct Wi-Fi Display |
2x2 MIMO HE160 4096 QAM 8 Spatial-stream Sounding MU-MIMO |
Bluetooth
Bluetooth is a standard for secure wireless data transfer between different types of devices over short distances.
Version The technology has several versions, which improve the connection speed, range, connectivity and discoverability of the devices. Information about the Bluetooth version of the device. | 5.2 |
Features Bluetooth uses various profiles and protocols related to faster exchange of data, energy saving, better device discoverability, etc. Some of those supported by the device are listed here. | A2DP (Advanced Audio Distribution Profile) LE (Low Energy) BLE SBC AAC LDAC |
USB
The Universal Serial Bus (USB) is an industry standard that allows different electronic devices to exchange data.
Connector type There are several USB connector types: the Standard one, the Mini and Micro connectors, On-The-Go connectors, etc. Type of the USB connector used by the device. | USB Type-C |
Version There are several versions of the Universal Serial Bus (USB) standard: USB 1.0 (1996), the USB 2.0 (2000), the USB 3.0 (2008), etc. With each following version the rate of data transfer is increased. | 3.1 |
Features Тhe USB interface in mobile devices may be used for different purposes such as battery charging, using the device as a mass storage, host, etc. | Charging Mass storage On-The-Go |
Gen 1 - 5 Gbps DP Alt Mode |
Headphone jack
The headphone jack is an audio phone connector, a.k.a. an audio jack. The most widely used one in mobile devices is the 3.5 mm headphone jack.
Headphone jack Information whether the device is equipped with a 3.5 mm audio jack. | No |
Connectivity
Information about other important connectivity technologies supported by the devices.
Connectivity Information about some of the most widely used connectivity technologies supported by the device. | Computer sync OTA sync Infrared Tethering NFC VoLTE Beidou Satellite News Tiantong Satellite Communication |
Browser
A web browser is a software application for accessing, fetching, displaying and navigating through information on the World Wide Web.
Browser Information about some of the features and standards supported by the browser of the device. | HTML HTML5 CSS 3 |
Audio file formats/codecs
Mobile devices support various audio file formats and codecs, which respectively store and code/decode digital audio data.
Audio file formats/codecs List of some of the most common audio file formats and codecs supported standardly by the device. | AAC (Advanced Audio Coding) AAC+ / aacPlus / HE-AAC v1 AC3 / AC-3 AMR / AMR-NB / GSM-AMR (Adaptive Multi-Rate, .amr, .3ga) AMR-WB (Adaptive Multi-Rate Wideband, .awb) aptX / apt-X aptX HD / apt-X HD / aptX Lossless eAAC+ / aacPlus v2 / HE-AAC v2 FLAC (Free Lossless Audio Codec, .flac) M4A (MPEG-4 Audio, .m4a) MIDI MP3 (MPEG-2 Audio Layer II, .mp3) OGG (.ogg, .ogv, .oga, .ogx, .spx, .opus) WMA (Windows Media Audio, .wma) WAV (Waveform Audio File Format, .wav, .wave) LDAC HWA |
Video file formats/codecs
Mobile devices support various video file formats and codecs, which respectively store and code/decode digital video data.
Video file formats/codecs List of some of the most common video file formats and codecs supported standardly by the device. | 3GPP (3rd Generation Partnership Project, .3gp) AVI (Audio Video Interleaved, .avi) DivX (.avi, .divx, .mkv) Flash Video (.flv, .f4v, .f4p, .f4a, .f4b) H.263 H.264 / MPEG-4 Part 10 / AVC video H.265 / MPEG-H Part 2 / HEVC MKV (Matroska Multimedia Container, .mkv .mk3d .mka .mks) QuickTime (.mov, .qt) MP4 (MPEG-4 Part 14, .mp4, .m4a, .m4p, .m4b, .m4r, .m4v) VP8 VP9 WebM WMV (Windows Media Video, .wmv) Xvid |
Battery
The batteries of mobile devices differ in capacity and technology. They provide the electrical charge needed for the functioning of the devices.
Capacity The capacity of a battery shows the maximum charge, which it can store, measured in mili-Ampere hours. | 5700 mAh (milliampere-hours) |
Type The battery type is determined by its structure and more specifically, by the chemicals used in it. There are different battery types and some of the most commonly used in mobile devices are the lithium-ion (Li-Ion) and the lithium-ion polymer battery (Li-Polymer). | Li-Polymer |
Charger output power Information about the electric current (amperes) and voltage (volts) the charger outputs. The higher power output allows faster charging. | 20 V (volts) / 5 A (amps) |
Features Information about some additional features of the device's battery. | Wireless charging Fast charging Non-removable |
80W wireless charging 20W reverse wireless charging |
